    Product Details:

    Place of Origin: China
    Brand Name: OFAN
    Certification: CE,UL,3C
    Model Number: LD175N-48D3-00

    Payment & Shipping Terms:

    Minimum Order Quantity: 1pcs
    Price: $10~30/pcs
    Packaging Details: 45*45*10
    Delivery Time: 5-8 work days
    Payment Terms: L/C, T/T, L/C, D/A, D/P, T/T, Western Union
    Supply Ability: 10000pcs
    Contact Now
    Detailed Product Description
    Impeller Material: Propylene With Glass-fiber Reinforced, Insulation Class: B
    Air Flow: 764m³/h Feature: High Performance

    Replace Ebm-past Dc Centrifugal Fan Air Purification with Pa66 175mm



    DC technology is not new. Not to OFAN at least. We developed our first EC compact fan in 2008, 10 years before our competitors started to market their EC products and 8 years before environmental protection was even an issue. In this time we have improved, refined and extended the OFAN EC range into the universal, high technology and reliable product that it is today.

    This means that OFAN EC gives you high performance, silent speed control and long life expectancy in a product which is the same size as the old, power hungry AC products it replaces.



    Listed
    Model
    Rated
    Voltage
    Operation
    Voltage
    Rated
    Current
    Power Rated
    Speed
    Air
    Flow
    Air
    Flow
    Air
    pressure
    Noise
    Level
    Part NO. VDC VDC A W RPM m³/h CFM mmH2O dBA
    LD175N-48D3-00 48 36~56 2.3 110 4200 692 408 48.4 81
    LD175N-48D3-01 48 36~56 1.2 57.6 3300 560 330 38.1 64
    LD175N-48D3-02 48 36~56 0.55 26.4 2500 365 215 18.1 60
    LD175N-28D3-00 28 18~32 4 112 4400 726 428 50.7 81
    LD175N-24D3-00 24 16~28 3 75 3800 626 369 43.7 70.
    LD175N-48D3-01 24 16~28 2.5 60 3300 560 330 38.1 64



























    Permanent-magnet brushless DC motor within the rotor


    The stator is driven by electronic switches (which replace the Carbon brushes), controlled by a microcontroller.


    Electronic system (hall effect sensor or software is used to recognize the rotor position)


    AC operated (230Volts Single phase or 380/480Volts 3phase, 50/60Hz)



    Why choose us?
    We belongs to the factory, so price we can give is based on factory cost, not trading cost.
    We are independent of factory. This make us standing in the position of client instead of factories. It will solve your problem of communication with factory.
    We absorb new knowledge and business way Internationally. This make us be able to give more marketing suggestion and new cooperation ways.



    Our Services

    Warranty: 1 year warranty for all products.

    Private Labelling: All of axial fans are able to be Private labeled.

    Products Quality: 100% products inspection before delivery.

    Just in time delivery: Normally, Lead time is 30 days.

     Prompt customers Services: E-mail will be replied in 24 hours.
