Continuous Control EC Centrifugal Blower Fan AC Operated 230 Volts Single Phase

Continuous Control EC Centrifugal Blower Fan AC Operated 230 Volts Single Phase

  • Continuous Control EC Centrifugal Blower Fan AC Operated 230 Volts Single Phase
  • Continuous Control EC Centrifugal Blower Fan AC Operated 230 Volts Single Phase
  • Continuous Control EC Centrifugal Blower Fan AC Operated 230 Volts Single Phase
Continuous Control EC Centrifugal Blower Fan AC Operated 230 Volts Single Phase
Product Details:
Place of Origin: China
Brand Name: OFAN
Certification: CE ROHS
Model Number: LD250C-230D3-03
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: Simple packing
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000PCS 15days
Contact Now
Detailed Product Description
Power Input: 130W Air Flow: 1410m³/h
Rated Speed: 2850RPM Nominal Voltage: 220V
Current Drwa: 0.87A Frequency: 50/60HZ
High Light:

industrial centrifugal blower

,

centrifugal fans and blowers



Ec Centrifugal Fans Filtering Ffu Save Electricity With 250mm



EC Motor – Principle
With an EC motor the electronic circuitry stands in lieu of the traditional mechanical commutation meaning the right amount is being supplied in the right direction at exactly the right time providing precise motor control.

Permanent-magnet brushless DC motor within the rotor
The stator is driven by electronic switches (which replace the Carbon brushes), controlled by a microcontroller.
Electronic system (hall effect sensor or software is used to recognize the rotor position)
AC operated (230Volts Single phase or 380/480Volts 3phase, 50/60Hz)





         Type

Nominal voltage

(VAC)

Frequency

   (HZ)

Speed

(RPM)

Power imput

(w)

Current draw

(A)

Sound pressure

(dB)

Perm.amb.temp



LD250C-230D3-03     220     50/60 2850 130 0.87 68 -25~+60





Energy savings : Minimum power consumption & better efficiency than AC equivalent.
Control : 100% speed controllable, not frequency dependant. Can be set-up for constant airflow or constant pressure applications, 0-10VDC or PWM control signal.
Low motor temperature : for longer lifetime than AC equivalent



Very high degree of efficiency

Integrated controller (continuous control)

Very simple connection

Additional functions (pressure control, airflow, speed, temperature, air quality, etc.)

Smaller-sized motor for the same level of performance

Less power consumption



1. Warranty: 1 year warranty for all products.

2. Private Labelling: All of axial fans are able to be Private labeled.

3. Products Quality: 100% products inspection before delivery.

4. Just in time delivery: Normally, Lead time is 30 days.

5. Prompt customers Services: E-mail will be replied in 24 hours.
