72W Sheet Metal 100mm Kitchen Exhaust Fan With Inline

Place of Origin China
Brand Name OFAN
Certification CE
Model Number FR250-10
Minimum Order Quantity 1
Price negotiation
Packaging Details 36*36*25
Delivery Time 5-8 day works
Payment Terms L/C, D/A, D/P, T/T
Supply Ability 100000PCS

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type FR250-10 Rated Voltage 220v
Input Power 72W Air Flow 250 M³/h
Highlight

100mm Kitchen Exhaust Fan

,

Inline Kitchen Exhaust Fan

,

72W Bathroom Extractor Fan

Leave a Message
Product Description

Inline Kitchen Exhaust Fan With Inline Bathroom Extractor Fan Sheet Metal 100mm





Our Service

Safe-common necessity of company and customers



Excellent –worker and product



Efficiency-worker and product



Environment-enterprise and society



OFAN provides the most comprehensive services, includes: product diversification, against the clock delivery, documents support, and technical consulting service. “Customer is partner” is key to our success; ”Win the contract for customer” is our ultimate goal.





TYPE

Rated Voltage

Input Power High(W)

Input Power

low(W)

Air Flow High(m³/h) Air Flow low(m³/h)

Noise Level High(dB)A

Noise Level low(dB)A

Tuyere diameter

Net Weight(kg)

FR150-10 220V/50HZ 58

49

150



100



28 27 100 25
FR250-10 220V/50HZ 72 62 250 200 30 29 100 26
FR350-15 220V/50HZ 98 83 350 300 34 32 150 32
FR450-15 220V/50HZ 148 118 450 400 36 34 150 33
FR550-20 220V/50HZ 186 149 550 500 38 36 200 38
FR650-20 220V/50HZ 225 180 650 600 40 38 200 39
FR800-20 220V/50HZ 390 310 800 700 41 39 200 46
FR1000-20 220V/50HZ 420 395 1000 900 43 41 200 47
FR1200-20 220V/50HZ 550 440 1200 1100 45 43 200 49
FR1500-25 220V/50HZ 780 585 1500 1300 46 43 250 86
FR2000-25 220V/50HZ 930 698 2000 1700 48 45 250 87
FR2500-25*35 220V/50HZ 1420 1065 2500 2200 49 46 250*350 108
FR3200-25*35 220V/50HZ 1680 1176 3200 2800 52 49 250*350 110
FR4000-30*36 220V/50HZ 2120 1485 4000 3500 54 50 300*360 175
FR5000-300*360 220V/50HZ 2460 1815 5000 4500 58 55 300*360 180



The products have been widely used in air supply and air exhaust in the hotels, conference rooms, supermarkets, stations and airports and other public places





RK type direct coupled centrifugal pipeline fan is a new type fan made by the domestic and foreign advanced technical design by our company. In order to be convenient for the air pipe connection, the inlet and outlet of the products have been designed according to the standard, and the two sides can conveniently connect with the air pipe, which is greatly reduce the costs of the pipeline design and production. This series fan has small volume, light weight, small vibration, low noise, long service life, high efficiency, good safety performance, and convenient installation and other characteristics. The products have been widely used in air supply and air exhaust in the hotels, conference rooms, supermarkets, stations and airports and other pubic places













FAQ

1. Are you a factory or trading company?

We are a factory which specialized in produce external rotor motor about 10 years. We accept OEM or ODM



2. How do I know which model I should choose

Please tell us the fans pressure and ofan and size of fans’ diameter you need. We will study and suggest you the right model.
